Main Features

• Sync collection for 12-lead ECG, adopt digital signal processing technology and get high-quality ECG waveform via power frequency filter, baseline filter and EMG filter of ECG signal.
• Display of 1/2/3-lead ECG, print mode, sensitivity, paper speed and filter state, etc. on one screen, convenient for contrastively diagnosing.
• Multiply printing modes and formats, including manual, auto 4×3, auto 3×4+1, auto 3×4, auto 2×6+1, auto 2×6, etc. Waveform length printed can be adjusted, and with time print function, which meets different requirements.
• With the functions of auto-analysis and auto-diagnosis for routine ECG parameters, provide measurement results and auto-diagnosis conclusion for HR, P-R interval, P Duration, QRS Duration, Q-T interval, Q-Tc, P Axis, QRS Axis, T Axis, R(V5), S(V1), R(V5)+S(V1), etc. which reduces the doctor’s burden.
• Built-in memory stores up to 15 cases(optional SD card, store up to 50 cases), convenient for case review and statistic.
• Two languages(Chinese or English) interface and report.
• AC/DC, and in optimal DC state, built-in rechargeable lithium battery can continuously work for 8-hour, print up to 70-minute and 175-ECG, which meets the requirements of visiting a patient at home and body examination.
